Contactor Non-Reversing 4 Pole, LC1D40008G6

(No reviews yet)
TeSys D contactors have been designed for perfect integration into control systems. They can be used to create motor starters for almost any type of application. TeSys D contactors are available in 13 contactor ratings for inductive motor applications up to 150 full-load amps and resistive loads up to 200 amps. This 4 pole IEC contactor can be mounted on DIN rail or mounted directly to a panel. Contactor has two normally open and two normally closed power contacts. Power contacts have a 60A resistive load rating. Contactor is supplied with a 120 VAC 60 Hz coil. Screw clamp terminals are used for load and auxiliary connections. An extensive line of accessories makes it easy to meet the requirements of most applications. The contactor is 5.00 inches tall, 3.35 inches wide and 4.92 inches deep. It weighs 3.17 lbs. Contactor is certified to UL, CSA, IEC, CCC, EAC and Marine standards. Contactor also meets the requirements of RoHS/REACh making it a Green Premium product.
Current Stock:
Adding to cart… The item has been added
Product Type   Contactor
Short Name   LC1D40008
Application   Resistive Load
Utilisation Category   AC-1
Poles Description   4P
[Ue] Rated Operational Voltage   Power circuit <= 690 V AC 25...400 Hz
Power circuit <= 300 V DC
[Ie] Rated Operational Current   60 A 140 °F (60 °C) <= 440 V AC AC-1 power circuit
[Uc]  Control Circuit Voltage   120 V AC 50/60 Hz
