RH-2 Double Rail Hinge Assembly w/c
Call For Pricing (800) 733-2231
(No reviews yet)
Write a Review
Handle-It
RH-2 Double Rail Hinge Assembly w/c
Established in 1932, Ace industries have supplied replacement, maintenance, and repair parts from original equipment manufacturers (OEM) for over 90 years. Our parts department has extensive knowledge of all Handle-It guard rails systems. At Ace Industries, we stock over 1000s of hoist parts and accessories that can be ready to ship the next day. We can assist in finding the right new in-stock part to fit your needs, whether the hoist is current or discontinued. Ace industries also sell brand-new electric chain, air powered, wire rope, and manual hoists; when it is time to replace your unit, contact an Ace Industries Professional at 800-733-2231 or visit our website aceindustries.com.
| Brand | Ingersoll Rand |
| Model | HLK |
| Capacity (Ton) | 1 |
| Lift (ft.) | 10 |
| Lifting Speed (FPM) | 26 |
| Reeving | 1 |
| Weight, Base Model (lbs.) | 84 lbs. |
- Ingersoll Rand HLK - The HLK Series incorporates a larger chain wheel to accommodate 3/8” diameter chain and a lower gear ratio to handle increased load capacities.
- Capacity & Lift - HLK Series hoist capacities range from 1 to 6 Ton and are severe-duty rated. With a standard lift of 10 feet.
- Motor - 100 percent duty-cycle multi-vane motor with high torque, low maintenance design, and air porting under vanes for smooth operation, positive starting, and long life.
- Frame - High-strength aluminum housing is strong, yet lightweight for maximum portability and weather resistance.
- Chain - Slack chain is guided into drive wheels by a specially designed opening that prevents dangerous cross-linking. A small amount of exhaust air flows over chain and drive wheel to help lubricate chain from spent in-line lubrication of motor.
- Brake - Air-operated, non-asbestos, self-adjusting disc brake balances effort to motor torque by sensing air pressure in the valve chest, providing precise control and eliminating back-drop encountered with some mechanical brakes; if air supply is interrupted, pressure release causes instantaneous, automatic braking
- Gears - Heat-treated planetary gearing system provides high-torque capability by splitting the torque path, thereby dividing and balancing the load over more teeth, assuring longer life and reduced maintenance.
- Safety - Upper and lower limit stops prevent dangerous over-travel of the hook in either direction, reducing possible damage to hoist or load. Manual brake release kit allows operators to safely lower a suspended load in a power failure.
