Rud 0.63 Ton Swivel Chain Lifting Point (PowerPoint PP VIP4 0.63t M12)
$165.00
The PowerPoint PP-VIP4-0.63t-M12 Direct VIP-Chain Connection is a compact, high-performance swivel lifting point designed for secure and efficient chain connections. With a 0.63-ton working load limit (1,389 lbs), it offers maximum versatility in lighter-duty lifting applications while maintaining the same safety and reliability found in larger PowerPoint® models.
- Direct chain integration: Universal, non-mix-up VIP clevis connection allows quick and secure attachment to chains without additional connectors.
- Superior flexibility: Rotates 360° and pivots up to 230° to accommodate multiple lifting angles safely.
- Smooth load movement: Built with a double ball bearing system that enables tilting, turning, and rotating under load for safer, smoother handling.
- Low kinking risk: 90° rotation to the bolt-on direction combined with cardan joint design reduces stress and prevents kinking.
- Compact strength: Small and lightweight design with robust load capacity, making it ideal for space-constrained lifting applications.
Need a different capacity or connection type? Explore the full catalog of available Rud products. To order from this catalog, just give us a call at (800) 733-2231.
| Capacity | 0.63 tons |
| Lifting Point Opening Height | 4 mm |
| Lifting Point Inner Dimension | 40 mm |
| Base Width | 36 mm |
| Threaded Rod Length | 18 mm |
| Thread Size | M12 |
| Head Room | 41 mm |
