Ingersoll Rand 3 Ton Beam Clamp (INGBC-3)
$264.00
(No reviews yet)
Write a Review
Ingersoll Rand
Ingersoll Rand 3 Ton Beam Clamp (INGBC-3)
Ingersoll Rand beam clamps provide temporary or permanent mounting options for a wide range of tapered or flat beams. These units have been designed and verified by actual pull testing to achieve a minimum design factor of 5:1 for vertical lifting with a powered or manual hoist, which meets ASME B30.16. These beam clamps offer quick or simple one-handed installation without requiring any tools. Units accommodate hook-mounted hoist or load blocks with minimal loss of headroom. The clamp jaws are designed to reduce beam stress by applying the load inside of the flange edge. Quick installation by hand and with no required tool.
| Model Number | INGBC-3 |
| Capacity (lbs) | 6000 |
| Beam Flange Width (in) | 3.15 - 14.76 |
| Weight (lbs.) | 23.1 |
- No Tools Required for Quick Hand Installation
- 1-ton to 5-ton capacities
- Mount hoists or lift beams with portable lightweight clamp
- Low headroom design adjusts to fit a wide range of flat or tapered beams
- Metric rated for vertical lifting or in-line pulling at 2200 lbs (1000 kg) per tone
- Meets ASME B30.16 for use with powered or manual hoists
